Extron electronics XTP II CrossPoint Series User Manual

5. Use an Extron Tweeker or small screwdriver to install the locking screw.
6. Close the power supply cabinet door and turn the door fastener counter-clockwise to
lock it shut.
Replacing and Terminating the Power Cable (XTP II CrossPoint 6400)
The XTP II CrossPoint 6400 has an attached power cable with a standard North
American 220 V plug. For switchers outside of North America, the attached power cable
is unterminated. The plug can be replaced with a termination that is more appropriate to
where you install the switcher and the entire cable can be replaced.
WARNING: High leakage current, earth connection is essential before connecting the
supply.
AVERTISSEMENT :
Courant de fuite éléve, le raccordement à la terre est indispensable
avant le raccordement au réseau.
ATTENTION:
• The outlet or junction box must be installed near the equipment and be easily
accessible.
• La prise de courant ou la boîte de jonction doivent être installées près du dispositif
et être facilement accessibles
• The installation location must provide short circuit and overcurrent protection, to a
minimum of 20 A.
• Le lieu d’installation doit disposer d’une protection contre les courts-circuits et la
surtension de 20 A minimum.
• Do NOT use an extension cord.
• Ne PAS utiliser de rallonge électrique.
Replacing or Installing the Power Plug
Replace or install the 220 VAC power plug as follows:
ATTENTION:
• Extron recommends that this procedure be performed by a licensed electrician only.
• Extron recommande que cette tâche soit exécutée par un électricien agréé
uniquement.
• The installation location must provide short circuit and overcurrent protection, to a
minimum of 20 A.
• Le lieu d’installation doit disposer d’une protection contre les courts-circuits et la
surtension de 20 A minimum.
• Do NOT use an extension cord.
• Ne PAS utiliser de rallonge électrique.
1. If the switcher is powered, unplug it or remove power from the power outlet or junction
box that powers the switcher.
2. Locally acquire a 220 VAC power connector that is standard for the region where the
switch is to be installed.
3. If necessary, cut the power cable just before the existing 220 V plug.
4. Trim the jacket back and strip the insulation from the line, neutral, and ground wires.
XTP II CrossPoint 1600, 3200, and 6400 Switchers • Maintenance and Modifications 147
