Button Icons
The numbered translucent covers on the input and output buttons can be removed and
replaced to insert labels behind the covers.
Input and output labels can be created easily with the Extron Button-Label Generator
software, which is shipped with every Extron matrix switcher. Each input and output can be
labeled with names, alphanumeric characters, or color bitmaps for easy and intuitive input
and output selection (see figure 33). See the Removing and Installing Button Labels,
on page 150, for details on using the labeling software, blank labels you can fill in yourself,
and a procedure for removing and replacing the translucent covers.
INPUTS
DVD
VCR
Computer Computer
Document
Camera
VTG 200
10 13 15
2928 30
8
9
8
9
31 32
Figure 33. Sample Button Icons
Front Panel Operations
The following sections detail the power-up process and then provide sample procedures for
the following actions:
• Creating ties, sets of ties, and configurations (see page 39)
• Changing a configuration (see page 41)
• Viewing ties, sets of ties, and configurations (see page 44)
• Saving a preset (see page 47)
• Recalling a preset (see page 48)
• Muting and unmuting outputs (see page 49)
• Viewing and Adjusting the Analog Input Audio Level (see page 51)
• Viewing and Adjusting the Analog Output Volume (see page 57)
• Locking and unlocking the front panel (see page 62)
• Performing front panel resets (see page 63)
• Toggling background illumination on and off (see page 64)
• Reading and setting the Remote port settings (see page 64)
XTP II CrossPoint 1600, 3200, and 6400 Switchers • Operation 37
