X6%
= GMT offset –12.0 through +14.0. Hours and minutes removed from GMT
X6^
= Daylight Savings Time 0 = Daylight Savings Time off or ignore
1 = Daylight Savings Time on (North America)
2 = Daylight Savings Time on (Europe)
3 = Daylight Savings Time on (Brazil)
X6&
= IP address ###.###.###.###
X6*
= Hardware (MAC) address ##-##-##-##-##-##
X6(
= Number of open connections 000 - 200
X7)
= Password Up to 12 alphanumeric characters
NOTE: The HTML language reserves certain characters for specific functions (see Special Characters on page 118).
X7!
= Domain name Standard domain name rules apply (for example: xxx.com)
NOTE: The HTML language reserves certain characters for specific functions (see Special Characters on page 118). The @ character is
acceptable only as the lead-in to the domain name (such as @extron.com).
X7#
= E-mail account 65 - 72. 65 = e-mail recipient 1, 66 = 2, 67 = 3, ... 72 = recipient #8
X7$
= E-mail address Typical e-mail address format (for example: nnnn@xxx.com)
X7% = Notification selections, part 1 I = inputs F = fans P = power supply
X7^ = Notification selections, part 2 If X7% = I, then X7^ = 00 (all inputs), or 01 through 16, 32, or 64 (input 1 through 16 [32 or 64])
If X7% = F, then X7^ = 00 (all fans)
If X7% = P, then X7^ = 00 (all power supplies).
X7&
= Notify when? 0 = no response 2 = fixed or restored 4 = suspend
1 = fail/missing 3 = both 1 & 2
X7*
= DHCP 0 = off (default), 1 = on
X7(
= Port number 01 = Remote RS-232/RS-422 port 02 Unused
03 — 130 = UARTs 1 — 128 (XTP input and output board ports)
X8)
= Baud rate 9600 (default), 19200, 38400, 115200
X8!
= Parity odd, even, none, mark, space (only the first letter required) (n = default)
X8@
= Data bits 7, 8 (default)
X8#
= Stop bits 1 (default), 2
NOTE: X7( through X8# and X9@ are repeated on page 78 as X1^ through X2!.
X8$
= Port type 0 = RS-232 (default) 1 = RS-422
X8%
= Verbose mode 0 = Clear or none (default for Telnet connection)
1 = Verbose mode (default for RS-232/RS-422 or USB connection)
2 = Tagged responses for queries
3 = Verbose mode and tagged for queries
NOTE: If tagged responses is enabled (modes 2 and 3), all read commands return the constant string and the value as the set command
does (for example, the read matrix name command ECN}, returns Ipn•X1@]).
X8^
= Flow control hardware, software, none (only the first letter required) (n = default)
X8&
= Data pacing (in ms between bytes) 0000 (default) - 1000
X8*
= Time (in 10 ms increments) to wait for characters 10 (= 100 ms, default) - 32767
X8(
= Time (in 10 ms increments) between characters 2 (= 20 ms, default) - 32767
X9)
= Priority status for receive timeouts : 0 = Use the “Send” data string command parameters if they exist (default)
1 = Use the Configure receive timeout command parameters
X9!
= Length of message (L) or delimiter (D) nnnnnL = byte count (1 – 32767 or 0 = ignore byte length, use time)
<delimiter>D (For example: 13D [carriage return —
}
])
X9@
= Port timeout interval (in 10-second increments) 1 (= 10 seconds) - 65000 (default is 30 = 300 seconds = 5 minutes)
XTP II CrossPoint 1600, 3200, and 6400 Switchers • Programming Guide 116
