13
=
=
ENGLISH
6A ADJUSTING THE CLOSING MECHANICAL STOPS
(DOUBLE LEAF)
The automatic door is supplied with the closing mechanical stops
installed on the mid-point of the support profile. If the door centre
requires adjustment, proceed as follows:
• Check if the mechanical stops are at the centre of the
profile.
• Take the leaf or leaves into the closing position.
• Loosen the securing screws of the carriages (Fig.21 ref.).
• Take the carriage close to the contact point until the two
touch.
• Re-tighten the carriage securing screws.
6.1A ADJUSTING THE CLOSING MECHANICAL STOPS (SINGLE
LEAF)
The automatic door is supplied with the closing mechanical
stops installed on the support profile. As the leaves close, make
sure that the carriages come into contact with the mechanical
stops. If adjustments are necessary, proceed as indicated for the
opening mechanical stops (chap 5A).
fig. 21
