FAAC A100 Compact - A100 COMPACT Glass Leaf

6
LH (max 2500)
17
150
24
43.6
24 ± 7.5
58
HA
21
25.8
22
4.5
12
4.5
10
100
10.5
ENGLISH
HA = (LH - 18,5) ± 7,5mm
HA = Leaf height
LH = height off the floor, level with
lower housing side
A100 COMPACT glass leaf
fig. 4
