16
ENGLISH
11A INSTALLING THE CLOSING HOUSING
• Lay the closing housing on the spacers you had previously
mounted, as shown in Fig. 26 or .
• To keep the housing open, lift it (Fig. 26 ref. ) and push it
(Fig.26 ref. ) toward the profile until the metal protrusion fits
in the profile seat.
• Secure the parachute cables in the appropriate seats (Fig. 26
ref. )
• The closing housing is locked in line with the two side panels
or the securing brackets (Fig. 26 ref. )
• The closing housing is pre-marked to adapt it to different leaf
thickness values. Eliminate excess profile by cutting at the
points indicated in fig. 26 ref. .
If you are using the internal release, in order to close
the housing correctly, drill a hole near the release
knob as shown in paragraph 16B.
fig. 26
