Installation manual
CNC 8035
APPENDIX
Summary of PLC inputs and outputs
E.
(SOFT M: V15.3X)
(S
OFT T: V16.3X)
·441·
SUMMARY OF PLC INPUTS AND OUTPUTS
GENERAL LOGIC INPUTS.
/EMERGEN M5000 Stops the axes and the spindle. Displays the error.
/STOP M5001 Stops execution of the part program, maintaining spindle rotation.
/FEEDHOL M5002 Stops axis feed momentarily, maintaining spindle rotation.
/XFERINH M5003 Prevents the next block from being executed, but finishes the one being executed.
CYSTART M5007 Starts program execution..
SBLOCK M5008 The CNC changes to single block execution mode.
MANRAPID M5009 Selects rapid travel for all the movements that are executed in JOG mode.
OVRCAN M5010 Selects feedrate override at 100%.
LATCHM M5011 The axes will move from the moment the corresponding JOG key is pressed until the
STOP key is pressed.
ACTGAIN2 M5013 Indicates that the CNC assumes the 2nd set of gains.
RESETIN M5015 Initial machining conditions selected by machine parameter.
AUXEND M5016 Indicates that the execution of the M, S and T functions has completed.
TIMERON M5017 Enables the timer:
TREJECT M5018 Rejection of tool in use.
PANELOFF M5019 Deactivation of keyboard.
PLCABORT M5022 Possibility to abort the PLC channel
PLCREADY M5023 PLC without errors.
INT1 M5024 Executes the interruption subroutine indicated in g.m.p. P35
INT2 M5025 Executes the interruption subroutine indicated in g.m.p. P36
INT3 M5026 Executes the interruption subroutine indicated in g.m.p. P37
INT4 M5027 Executes the interruption subroutine indicated in g.m.p. P38
BLKSKIP1 M5028 The “/ and /1” block skip condition is met.
BLKSKIP2 M5029 The “/2” block skip condition is met.
BLKSKIP3 M5030 The “/3” block skip condition is met.
M01STOP M5031 Stops execution of the part program when the auxiliary M01 function is executed.
RETRACE M5051 It activates the Retrace function.
ACTLM2 M5052 Activates the second travel limits.
HNLINARC M5053 Type of path with "Path Handwheel" or "Path jog".
MASTRHND M5054 It activates the "Path Handwheel" or "Path jog" mode.
EXRAPID M5057 Selects rapid travel for all the movements that are executed in execution mode.
FLIMITAC M5058 Limit the feedrate of each axis to the value set in its machine parameter FLIMIT (P75).
SLIMITAC M5059 Limit the spindle speed to the value set in its machine parameter SLIMIT (P66).
BLOABOR M5060 Finish the movement in progress and start executing the next block.
ACTGAINT M5063 Indicates that the CNC assumes the 3rd set of gains.
SKIPCYCL M5064 Go on to the next hole after a retraction in a drilling or a mill type threading.
RETRACYC M5065 It indicates that the Z axis has been stopped before starting the retraction.
