447153 ISSUE I REV. A PAGE 3 OF 4
413699 EVENT CODES
Event Type SIA DCS
(8 or 20)
Ademco
Contact ID
3/1 *
1400HZ or 2300HZ
4/2 **
1400HZ or 2300HZ
Fire Alarm FA tuvw 1 110 00 xyz 0 01
Sprinkler Alarm SA tuvw 1 113 00 xyz 0 02
Fire Alarm Restore FH tuvw 3 110 00 xyz 2 21
Sprinkler Alarm Restore SH tuvw 3 113 00 xyz 2 22
Fire Supervisory FS tuvw 1 200 00 xyz 6 64
Sprinkler Supervisory SS tuvw 1 203 00 xyz 6 66
AC Restore AR 3 301 00 7 70
Power Up RR 0 1 305 00 0 7 70
Fire Unbypass FU tuvw 3 571 00 xyz 7 71
Phone Line 1 Restore LR 1 3 351 00 1 7 71
Phone Line 2 Restore LR 2 3 352 00 2 7 72
Fire Trouble Restore FJ tuvw 3 373 00 xyz 7 73
Fire Trouble Restore (all clear) FJ 9 3 373 00 9 7 79
Fire Restore FR tuvw 3 110 00 xyz 7 74
Sprinkler Trouble Restore SJ tuvw 3 203 00 xyz 7 75
Sprinkler Restore SR tuvw 3 203 00 xyz 7 76
System Battery Restore YR 3 302 00 7 77
AC Trouble AT 1 301 00 8 80
Fire Bypass FB tuvw 1 571 00 xyz 8 81
Phone Line 1 Trouble LT 1 1 351 00 1 8 81
Phone Line 2 Trouble LT 2 1 352 00 2 8 82
Fire Trouble FT tuvw 1 373 00 xyz 8 83
System Battery Trouble YT 1 302 00 8 87
Fire Test Begin FI 0 1 604 00 0 9 90
Fire Test End FK 3 604 00 9 92
Automatic Test(unit normal) RP N 1 602 00 N 9 93
Automatic Test (unit abnormal) RP A 1 602 00 A 9 93
Manual Test (unit normal) RX N 1 601 00 N 9 94
Manual Test (unit abnormal) RX A 1 601 00 A 9 94
* The 1-digit code is programmable (3/1 codes).
** The first digit is programmable (3/1 codes)
SIA DCS
EVENT CODE IDENTIFIER DESCRIPTIONS
4 Digit Code t u v w
Sensor 0 Address (100-499)
Module 1 Address (100-499)
3 Digit Code t u v
NAC Trouble 2 Circuit (01-12)
Trouble 2 9 8
GND Trouble 2 9 9
IDC 3 Circuit (01-08)
9
ADEMCO CONTACT ID
EVENT CODE IDENTIFIER DESCRIPTIONS
x y z
Sensor Loop 1 0 Address (00-99)
Module-Loop 1 1 Address (00-99)
NAC Trouble 2 Circuit (01-12)
Trouble 2 9 8
GND Trouble 2 9 9
IDC 3 Circuit (01-08)
Sensor-Loop 2 4 Address (00-99)
Module-Loop 2 5 Address (00-99)
Sensor-Loop 3 6 Address (00-99)
Module-Loop 3 7 Address (00-99)
Sensor-Loop 4 8 Address (00-99)
Module-Loop 4 9 Address (00-99)
