3. Product description
36 Festo.P.BE-CMMS-ST-G2-HW-EN 1008NH
Setting the operating mode
Due to a necessary synchronisation of internal processes, the change of operation mode
can require some cycle times of the controller. We therefore recommend that you always
verify and wait for reception of the desired operation mode.
Operating mode Syntax Response
Regulating torque OW:0030:00000004
Speed adjustment OW:0030:00000008
Positioning OW:0030:00000002
OK! or OW:EEEEEEEE
Table 3.12 Operating mode
Faulty return values can be called up due to invalid values that do not come from the
above-named group. The current operation mode can be read by using the “OR”
command.
Control via RS-485
Note
Before activating the RS-485 interface, please make sure that you
are using a completely wired null modem cable. All pins of the
cable must be occupied according to the following specification
(also see chapter 6.4.5).
Pin Brief
description
Name Signal direction Description
1 DCD Data carrier detect
Transfer device -->
end device
Data carrier signal was recorded by
transfer device.
2 RxD Receive (x) Data
Transfer device -->
end device
Line at the end device that receives a
data bit from the transfer device.
3 TxD Transmit (x) Data
End device -->
Transfer device
Line at the end device that sends a data
bit to the transfer device.
4 DTR Data terminal ready
End device -->
Transfer device
End device is ready for use.
5 GND Ground (earth) None Reference potential at 0 V.
6 DSR Data set ready
Transfer device -->
end device
Transfer device is ready for use.
7 RTS Request to send
End device -->
Transfer device
End device displays that the remote
station should send (send request).
8 CTS Clear to send
Transfer device -->
end device
Transfer device shows reception
readiness (send permission).
