Festo CMSH - Page 49

Festo — CMSH — 2021-10
Commissioning
49
Value Description
Exhaust output 2 Working port (2) is exhausted. Working port (4) is pressurised.
Pressurize out 2 Working port (2) is pressurised. Working port (4) is exhausted.
Lower end pos. Controlled procedure for the lower end position.
Upper end pos. Controlled procedure for upper end position.
Execute PST Partial Stroke Test is executed.
Lock interface Local operation is blocked.
Tab. 47: DI1 function
DI1 target position
The ‘DI1 target position’ parameter shows the user-defined setpoint position that is approached when
the function at digital input 1 has been set to ‘Hold user TPOS’.
Value range Description
0.0 … 100.0% Permissible setting range, factory setting 0.0%
Tab. 48: DI1 target position
‘Digital Input 2’ menu
DI2 logic
The ‘DI2 logic’ parameter defines the switching logic for activating the function of the digital input 2.
Value Description
ACTIVE LOW Switching logic ‘ACTIVE LOW’
The set function is activated at a low level.
ACTIVE HIGH Factory setting: switching logic ‘ACTIVE HIGH’
The set function is activated with a high level.
Tab. 49: DI2 logic
DI2 function
The ‘DI2 function’ parameter defines the behaviour of the positioner when digital input 2 has been
activated.
Value Description
inactive Factory setting: inactive
Execute init Initialisation is executed.
Hold last TPOS Last setpoint position is held.
Hold user TPOS User-defined setpoint position is maintained
è
‘Digital Input 2’ menu.
Close outputs Working port (2) and working port (4) are closed.
Exhaust output 2 Working port (2) is exhausted. Working port (4) is pressurised.
Pressurize out 2 Working port (2) is pressurised. Working port (4) is exhausted.
