Commissioning
Value Description
Lower end pos. Controlled procedure for the lower end position.
Upper end pos. Controlled procedure for the upper end position.
Execute PST Partial Stroke Test is executed.
Lock interface Local operation is blocked.
Tab. 50: DI2 function
DI2 target position
The ‘DI2 target position’ parameter defines the setpoint position that is approached when the function
at digital input 2 has been set to ‘Hold user TPOS’.
Value range Description
0.0 … 100.0% Permissible setting range, factory setting 0.0%
Tab. 51: DI2 target position
DO switching mode
The ‘DO switching mode’ parameter defines the switching behaviour of the digital outputs.
Value Description
NAMUR Factory setting: NAMUR output (current-switching)
SPS PLC output (voltage switching)
Tab. 52: ‘DO switching mode’ menu
‘Digital Output 1’ menu
DO1 logic
The ‘DO1 logic’ parameter defines the switching logic of the function of the digital output 1.
Value Description
ACTIVE LOW Switching logic ‘ACTIVE LOW’
The low level is output at digital output 1 if the assigned function or the
status to be acknowledged is active.
ACTIVE HIGH Factory setting: switching logic ‘ACTIVE HIGH’
The high level is output at digital output 1 if the assigned function or
the status to be acknowledged is active.
Tab. 53: DO1 logic
DO1 function
The ‘DO1 function’ parameter defines the statuses that are fed back via the digital output.
