2. Commissioning
2-14
Festo P.BE-CPX-FB32-EN en 1111a
Module
no.
Module Input address Output address
0 Fieldbus node CPX-FB32 – –
1 Digital 8-input module CPX-8DE I32 ... I39 –
2 Digital 4-output module CPX-4DA – O128 ... O135
*)
3 CP interface
CP-I, here: 4 byte I, 16 byte O
I0 ... I32 O0 ... O127
4 Digital multi I/O module
CPX-8DE-8DA
I40 ... I47 O136 ... O143
5 MPA1 pneumatic module (8 DO) – O144 ... O151
6 MPA1 pneumatic module (8 DO) – O152 ... O159
*)
8 bits occupied, 4 bits used
Tab. 2/9: Addressing the example terminal 2 (see Fig. 2/2)
