Further relevant documents
For all available product documentation è www.festo.com/pk
This document contains information about the mounting, installation, commissioning, maintenance and
conversion of the product.
The following documents contain further details:
Name, type Table of contents
System description CPX terminal Detailed description of the CPX system, overview of
descriptions of the CPX modules
Brief description VMPAL-EPL-
SD.../-FL.../-KL...
Valve terminal with multi-pin plug connection:
Brief description VMPAL-EPL-IPO32 Valve terminal with I-Port/IO-Link interface:
Assembly
instructions
Valve terminal MPA Wall mounting and H-rail mounting of the valve
terminal MPA with multi-pin plug connection
Assembly
instructions
Terminal CPX with
valve terminal MPA
Wall mounting and H-rail mounting of the valve
terminal MPA with CPX terminal
Assembly
instructions
VMPA...-B8-R...C2-C... Mounting the pressure regulator plates
Assembly
instructions
VMPA1-HS Mounting the vertical pressure shut-off plates
Assembly
instructions
VMPA1-FT-NW...-10 Mounting the fixed restrictors
Assembly
instructions
VMPA...RV Mounting the check valves
Assembly
instructions
ASLR-D-L1 Mounting the inscription label holders
Assembly
instructions
VMPA-HB...-B Mounting the cover caps VMPA-HB...-B
Assembly
instructions
VAMC-L1-CD Mounting the cover caps VAMC-L1-CD
Assembly
instructions
VMPAL-LW Using the releasing tool for electrical interlinking
Tab. 1 Documents relating to the product
Service
Contact your regional Festo contact person if you have technical questions è www.festo.com.
