A.1.3 Pneumatics
Solenoid valves
Operating/pilot medium Compressed air to ISO 8573-1:2010 [7:4:4]
Note about the operating/pilot medium Lubricated operation possible (in which case lubricated
operation will always be required)
Design Piston slide valve
Polymer poppet valve
Manual override Detenting or non-detenting
Operating pressure/pilot pressure
All valves at connection (1) The pressure at port (1) must be within the required control
pressure range of the valves
(è Diagrams Fig. A.1 … Fig. A.6, max. 8 bar).
Valves with external pilot air
Valves with ID codes B,
E, G, J and M at the
port (1)
[bar] –0.9 … 10
Valves with ID codes
DS, HS, KS, MS and NS
at the port (1)
[bar] –0.9 … 8
Valves with ID code W
at the port (2)
[bar] –0.9 … 10
Valves with ID code X
at the port (4)
[bar] –0.9 … 10
Valves with ID codes D,
H, I, K and N at the
port (1)
[bar] 3 … 10
Valves with ID codes
MU, NU, KU and HU at
the port (1)
[bar] –0.9 … 10
All valves at connection
(12/14)
[bar] è Diagrams Fig. A.1 … Fig. A.6, pressure P2 (max. 8 bar)
Tab. A.3 Technical data: solenoid valves
