8 Dismounting
92 Festo – MPAL-VI-EN – 2017-07a – English
8 Dismounting
8.1 General instructions for dismounting
Warning
Uncontrolled movements of the connected actuator technology and loose tubing can
cause injury to persons and/or damage to property.
Before carrying out mounting, installation and maintenance work, switch off the
following power sources:
– Compressed air supply
– Operating voltage supply
– Load voltage supply
Electrostatically sensitive components:
Do not touch electrical and electronic components.
8.2 Dismounting from H-rails
There is a guide groove at the back of the valve terminal for attaching to the H-rail.
Variant
Valve terminal with multi-pin plug connection and valve terminal with I-Port/IO-Link interface
1
1
Valve terminal with CPX terminal
1 M4 retaining screw 2 M6 retaining screw
