A Technical appendix
Festo – MPAL-VI-EN – 2017-07a – English 95
A Technical appendix
A.1 Technical data
A.1.1 General
Mechanical
Mounting position
H-rail mounting Only horizontal
– Valve terminal with multi-pin plug connection or
I-Port/IO-Link interface èAssembly instructions
for valve terminal MPA
– Valve terminal with CPX terminal èAssembly instruc
tions for terminal CPX/valve terminal MPA
Wall mounting Optional
– Valve terminal with multi-pin plug connection or
I-Port/IO-Link interface èAssembly instructions for
valve terminal MPA
– Valve terminal with CPX terminal èAssembly instruc
tions for terminal CPX/valve terminal MPA
Weights
Multi-pin connection plate [g] 130
Pneumatic interface [g] Approx. 210
Supply module
(With seal, electrical
interlinking, exhaust
plate)
[g] 87
(With seal, electrical
interlinking, flat plate
silencer)
[g] 92
Sub-base (with seal, electrical interlinking)
1 valve position [g] 30
4 valve positions [g] 113
Right end plate
Without supply ports [g] 105
With supply ports [g] 161
Valve, size
MPA1 [g] Approx. 56
MPA14 [g] Approx. 77
MPA2 [g] Approx. 100
