The batteries don’t work properly
1. The batteries are not properly con-
nected
⇒ Restore the proper battery connec-
tions.
2. The batteries are discharged ⇒ Perform a complete charge cycle.
3. Battery terminal are oxidized ⇒ Disconnect the batteries, clean the
batteries terminals and reconnect
properly the batteries.
4. With the machine in working con-
ditions one battery has a voltage
lower (difference higher than 2 V)
than the other ones
⇒ Replace the battery with lower volt-
age.
5. The fuse on the loop wire is dam-
aged
⇒ Check for possible short circuits, If
not present replace the loop wire.
6. The power wires are damaged ⇒ Replace the damaged wires.
7. The battery charger is not properly
adjusted
⇒ Adjust the battery charger properly
(see section 6.4.2 at page 46).
8. The battery charger doesn’t work ⇒ Check the proper section (see section 3.1
at page 11).
The battery charger doesn’t work
1. The battery charger is not con-
nected to the power supply
⇒ Connect the charger to a supplied
electric socket.
2. The battery charger is not con-
nected to the batteries
⇒ Connect the charger to the batteries.
3. The battery charger has one or
more lights (or LEDs) blinking con-
tinuously
⇒ The battery charger is in error con-
ditions, verify the alarm tables and
solve the issue by following the re-
lated instructions (see section 6.4.2 at page
47).
4. The battery charger is properly con-
nected but it doesn’t switch on
⇒ Replace the battery charger.
