Fimap MXR - 2 Main Technical Features

Chapter 2
Main Technical Features
Technical Data
TECHNICAL DESCRIPTION U/M Mxr
Working width mm 560
Working capacity, up to
m
2
h
2632
Steering Diameter mm 1980
Maximum Ramp Gradient % 8
Total Power W 1060
Machine Length mm 1265
Machine length (with optional storage compartment) mm 1400
Machine Height mm 1030
Machine Height (with optional blinking kit) mm 1070
Machine Width (with squeegee) mm 705
Machine Width (with optional squeegee) mm 800
Machine Width (without squeegee) mm 600
Machine Width
(without squeegee with optional toolbox kit)
mm 620
Wheel Base mm 730
Wheel Track mm 520
Footrest height from the ground mm 230
Seat height from the footrest mm 466
Handlebar distance from the back seat mm 530
Sound pressure level (ISO 11201) LpA dB (A) 63
Hand vibration level (ISO 5349)
m
s
2
≤ 2.5
Body vibration level (ISO 2631)
m
s
2
≤ 0.5
7
