Fimap MXR - Technical Features

Check / Monitor
Check / Monitor:
I Tr: ### [Amp]
Show current of traction motor.
Check / Monitor:
I Br: ## [Amp]
Show current of brush motor.
Check / Monitor:
I Vac: ## [Amp]
Show current of vacuum motor.
Check / Monitor:
V Tr: #### [V]
Show voltage of traction motor.
Check / Monitor:
V Batt: #### [V]
Show battery voltage.
Check / Monitor:
Vref: ### [V]
Show the voltage reference of the traction pedal.
Check / Monitor:
Wtr Pump: ### [%]
Parameter not managed.
Check / Monitor:
Det Pump: ### [%]
Parameter not managed.
Check / Monitor:
BR Temp: ## [C]
Show temperature inside of main card, related to brush/vacuum.
Check / Monitor:
TR Temp: ## [C]
Show temperature inside of main card, related to traction.
Check / Monitor:
TR Ovrld: ### [%]
Show the percentage value of the amperometric protection of traction motor (when 100%
the amperometric protection cuts the current).
Check / Monitor:
J7:
Check of the microswitches functioning:
2 ⇒ Battery Charger (active if the charger is OFF or missing)
4 ⇒ Traction Pedal Microswitch
5 ⇒ Curve Reduction Speed Microswitch
7 ⇒ Squeegee Lever Microswitch
15 ⇒ Seat Microswitch
17 ⇒ Brush Deck Lever Microswitch
6.8 Technical Features
TECHNICAL DESCRIPTION U/M Mxr
Dimension of Battery compartment (l x L x h) mm 362x354x290
Batteries Rated Voltage
V
Ah
2x(12/105)
Maximum batteries weight kg 2x41
