Fimap MXR - Recommended Spare Parts

4.1.3 Machine Frame and Traction System
PN Description
436222 FRONT WHEEL D=175 d=20 S=60 WITH BEARINGS
426460 REAR WHEEL D=225 L=69
Carbon Brushes
422462 TRACTION MOTOR CAR.BR.
4.2 Recommended Spare Parts
The following table refers to the Recommended Spare Parts, and reports the amount suggested by
the number of purchased machines.
Machines Parts
1 ⇒ 1
10 ⇒ 2
25 ⇒ 3
50 ⇒ 4
4.2.1 Electrical System
PN Description
438767 MAIN CARD 7CFCP001
436267 CONTROL CARD
436268 SERIAL CABLE FOR CONTROL CARD
223940 TRACTION PEDAL ASSEMBLY
210516 COMPLETE KEY SWITCH
409499 MICROSWITCH 3X22 L.C.FLAT
409503 SEAT MICROSWITCH
216691 COMPLETE SEALED MICROSWITCH
436144 EMERGENCY BUTTON
222386 BATTERY CHARGER KIT
4.2.2 Mechanical Rubbing System
PN Description
222452 GEAR MOTOR 24V 400W 140RPM H2O W/MOLEX
436120 BASE BUMPER WHEEL D=100 H=20
436124 BRUSH FLANGE
19
