The selections provided for PTFI*MTFI timings are:
Table 13: PILOT AND MAIN TRIAL FOR IGNITION TIMING
SELECTION
PTFI
MTFI
COMMENT
Term 5
(Term W for YP148/YP184
Programmer)
Term 6
(Term 5 for YP148/YP184
Programmer)
Term 5
(Term W for YP148/YP184
Programmer)
Term 6
(Term 5 for YP148/YP184
Programmer)
10/10*10/15
10
10
10
15
5/5*0/10
5
5
0
10
NO SPARK DURING MTFI
5/5*0/5
5
5
0
5
NO SPARK DURING MTFI
5/5*10/15
5
5
10
15
SHORTENED PTFI
5/5*10/10
5
5
10
10
SHORTENED PTFI
5/10*0/15
5
10
0
15
EARLY SPARK TERMINATION
5/10*0/10
5
10
0
10
EARLY SPARK TERMINATION
10/10*0/10
10
10
0
10
NO SPARK DURING MTFI
10/10*0/5
10
10
0
5
NO SPARK DURING MTFI
10/10*10/10
10
10
10
10
Note: For YP148 and YP184 programmers, the above table applies to terminals
W (Igniter) and 5 (Pilot) operation during PTFI and MTFI.
