Table 15: MODIFIABLE PARAMETERS LOCATED IN PROGRAM SETUP MENU
0:00s – 60:00m, 1 second
increments.
0:00s-60:00m, YP113
0:00s-60:00m, YP115 (0:00s - 60:00m in YP3XX)
Applies to open damper purge time in YP1XX and YP2XX pro
grammers and low fire
start time in YP3XX programmers.
Note: 0 sec purge requires a display with Engr code 9 or higher
and chassis Engr code
of 11 or higher
Time counts UP to final value or DOWN to zero from starting value.
This setting will
apply to all timer values.
Prevents jumped terminals. Requires the 3-P circuit to be open at
the start of a cycle.
10/10*10/15
YP113 = 5/5*3/5
YP148, YP184 =
10/10/10/10
Applies to terminals 5 and 6 operation during PTFI and MTFI.
Applies to terminals W and 5 operations during PTFI and MTFI in YP148 and YP184
programmers.
Terminal 6 interrupted
or intermittent
Provide interrupted or intermittent operation on terminal 6.
Provide interrupted or intermittent operation on terminal 5 in YP148 and YP184
programmers.
If YES, M-8 must be open at start of open damper purge period.
(YP1XX Series only).
If YES, M-D must be open at end of open damper purge period.
Does not apply to
YP3XX Series.
0:00s - 4:00m, 1 second
increments.
Applies to YP3XX series only. Allows non-recycle operation of 3-P
circuit.
Select YES for lockout on M-D open for 10 minutes. Select NO for indefinite wait for M-D
to close. This wait time applies prior to pilot
trial for ignition.
Select YES to force lockout on M-D opening during PTFI and MTFI
Sets communication baud rate
Multi-drop requires unique addressing. Lowest address allowed
for modbus is 01
Parameters can be stored to memory before automatic 8-hour
store.
Does not apply to YP148/YP184 Series.
Select YES to activate IR LEARN process. See IR operation.
IR LEARN feature for eng code 12 and lower only
Applies to YP148 and YP184 programmers only.
Select Enable to execute the Valve Proving during sequencing.
Note: Requires a display with Engr code 17 or higher.
Applies to YP148 and YP184 programmers only.
Select Pre-Purge to execute valve proving prior to pre-purge timing.
Select Post-Purge to execute valve proving after the post-purge is complete, before
returning to standby. When VP at Post-Purge is selected, VP at Pre-Purge is executed once
upon every first power-on cycle.
Note: Requires a display with Engr code 17 or higher.
Applies to YP148 and YP184 programmers only.
Time to verify leakage in upstream valve (MV1) during valve proving evacuation test. Can
be set in 5 second increments.
Note: Requires a display with Engr code 17 or higher.
Applies to YP148 and YP184 programmers only.
Time to verify leakage in downstream valve (MV2) during valve proving pressurization test.
Can be set in 5 second increments.
Note: Requires a display with Engr code 17 or higher.
Applies to YP148 and YP184 programmers only.
Select enable to monitor the gas pressure switch after the downstream gas valve opens to
detect the low gas pressure in fuel train.
Note: Requires a display with Engr code 17 or higher.
Applies to YP148 and YP184 programmers only.
Select YES to enable Burner control ON/OFF operation.
NOTE: Selecting BRNR CNTRL EN as “NO” shall make BURNER parameter as non-
modifiable (read-only)
Note: Requires a display with Engr code 17 or higher.
Applies to YP148 and YP184 programmers only.
Select ON to turn ON the Burner control. Select OFF to turn OFF
the Burner control provided Terminal 3 is in energized state.
Note: Requires a display with Engr code 17 or higher.
LEGEND: Shaded parameters not affected by 8-hour burn-in or LOCK SETTINGS.
