BURNERLOGIX PROGRAMMER SELECTION
All programmers for the BurnerLogiX Series are designated with the prefix “YP”. The functional
operation, flame failure response time, purge timings, firing rate motor circuit, trial for ignition tim-
ings, recycling function, valve proving function, LGP function, Burner On/Off function and display
messages are determined by the programmer.
Table 12 contains the most common programmers.
Check the programming sequence table for each programming module for the proper explanation of
prepurge timings.
WARNING: THE INAPPROPRIATE SELECTION OR APPLICATION OF A PROGRAMMER MODULE CAN
RESULT IN AN UNSAFE CONDITION HAZARDOUS TO LIFE AND PROPERTY. The various programmer
modules are interchangeable because they plug into a common YB chassis. Many parameters are
configurable through the keypad display. Care must be taken to ensure the proper parameters are
set. Refer to the appropriate programmer bulletin for appropriate settings. Selection of the
programmer module and setting the various parameters for a particular application must be made
by a competent professional, such as a Boiler/Burner technician licensed by a state or government
agency, engineering personnel of the burner, boiler, or furnace manufacturer (OEM) or in the
performance of duties based on the information from the OEM.
CAUTION: FOR IR MODELS, PRIOR TO VERSION 12, IT IS HIGHLY RECOMMENDED THAT AN "IR
LEARN" OPERATION BE PERFORMED TO GUARANTEE RELIABLE OPERATION. REFER TO IR LEARN
SECTION FOR MORE INFORMATION.
