LOCKOUT CODES
During an alarm condition, the Alarm LED is made to flash at approximately a twice per
second rate. The remaining LEDs are illuminated as a coded sequence identifying the reason for the
lockout. This remains true if power is removed and then restored in a locked-out condition.
Table18: LED LOCKOUT CODES
LED DISPLAY READOUT
⚫
= ON
LOCKOUT MESSAGE
FAN
OPEN DAMPER
CLOSE
DAMPER
AUTO
IGN
FLAME
T13 FUEL VALVE END SWITCH OPEN
⚫
⚫
M-D LOW FIRE START OPEN
⚫
⚫
M-D LOW FIRE START OPEN - PTFI
⚫
⚫
⚫
M-D LOW FIRE START OPEN - MTFI
⚫
⚫
⚫
⚫
M-D CLOSED
⚫
⚫
M-8 CLOSED
⚫
⚫
M-8 HIGH PURGE CIRCUIT OPEN
⚫
FALSE FLAME-STANDBY
⚫
⚫
FLAME FAIL PTFI
⚫
⚫
⚫
⚫
FLAME FAIL - MTFI
⚫
⚫
⚫
⚫
⚫
3-P RUN INTLK OPEN-VALVE PROVE
⚫
⚫
FLAME FAIL AUTO
⚫
⚫
⚫
3-P RUN INTLK OPEN - PREPURGE
⚫
⚫
⚫
3-P RUN INTLK OPEN - PURGE
⚫
⚫
⚫
3-P RUN INTLK OPEN-PTFI
⚫
⚫
3-P RUN INTLK OPEN-MTFI
⚫
⚫
⚫
3-P RUN INTLK OPEN-VALVE PROVE
⚫
⚫
3-P RUN INTLK CLOSED- STANDBY
⚫
3-P RUN INTLK OPEN- AUTO
⚫
FUEL VALVE STATE CHANGE
⚫
CHECK FUSE
⚫
⚫
⚫
CHECK WIRING
⚫
⚫
⚫
CHECK SCANNER
⚫
⚫
⚫
CHECK PROGRAMMER
⚫
⚫
CHECK CHASSIS
⚫
CHECK EXPANSION MODULE
⚫
⚫
⚫
⚫
EVAC TEST FAIL
⚫
⚫
⚫
PRES TEST FAIL
⚫
⚫
LGP CHECK FAIL
⚫
⚫
⚫
