Fireye BurnerLogiX YB110 User Manual

© 2023 Carrier 54
10. If flame is detected when the operating control (L1-3) is open, the control waits sixty (60) seconds and
then locks out if flame is still present. If the operating control closes and flame is detected during purge, the
control drops back to the Standby position and de-energizes the blower motor (Term M). If the flame signal goes
away within sixty (60) seconds, the control proceeds with a normal start-up. If flame signal is still present after
sixty (60) seconds, the control locks out.
11. If the fuel valve end switch connected to Terminal 13 is not closed after 5 seconds into post purge, the control
locks out on safety.
12. If the LGP switch connected to Terminal 21 is not proven by the end of the first five seconds of MTFI/MFEP
or is not proven during the entire run state, the control locks out on safety.
13. If the VPS connected to Terminal 23 is not proven during the evacuation test or the pressurization test, the
control lockouts out on safety.
DIAGNOSTIC MESSAGES
Table 17:
MESSAGE
POSSIBLE CAUSE
SOLUTION
CHECK
PROGRAMMER
No programmer module plugged
into YB chassis/amplifier module
Remove power, insert programmer, press reset to clear fault
Defective programmer module
Remove power, replace programmer module
CHECK CHASSIS
Relay feedback error caused by
bad wiring
Check all wiring, Re-inspect routing of all wires
Programmer module inserted
while power is applied
Cycle power, reset control
Defective opto-coupler on the YB
chassis/amplifier
Replace YB module
CHECK WIRING
Voltage is detected on terminals at
improper time
Check system wiring. Measure voltages on input/output terminals
CHECK SCANNER
Flame signal detected during shutter
close time in 45UV5 or 55UV5
scanner
Check power on shutter terminals and/or replace shutter in scanner.
Runaway UV tube
Replace UV tube, part number 4-314-1
CHECK EXPANSION
MODULE
Internal diagnostics within expansion
module has detected a problem and
ceased communications with
BurnerLogix control for 3 minutes.
Check that ED580 cable from expansion module to BurnerLogix is
plugged in or not damaged, check routing of cable within burner
cabinet or check L1-L2 connections to expansion module. Reset
control and check STATUS LED on expansion module. Replace
YZ300 or YZ320 expansion module or YB110 (YB230) chassis/
amplifier module.
Defective or unplugged ED580
cable.
Assure cable is fully inserted in both BurnerLogix control and
Expansion module. Check for damage to cable or connectors.
WAITING FOR DATA
Communications to/from display
Indicates the display is not communicating properly with chassis. Check that
the YP programmer is properly inserted. Check that the cable is not defective
and is properly inserted into the connectors. In rare instances due to ongoing
enhancements to the BurnerLogix family, the display and chassis may not
be compatible. Check the date code and engineering code of both sets.
RESETTING THE CONTROL
The BurnerLogix systems contains three methods of reset. These are by:
1. push-button located on the YB chassis/amplifier module.
2. keypad push-button located on the optional keypad/display module.
3. user installed normally open push-button connected from line voltage (L1) to Terminal 22.
Terminal 22 is a line voltage isolated input. Depressing and releasing the reset button is required.
