Fireye BurnerLogiX YB110 User Manual

© 2023 Carrier 61
OUTPUTS (40008)
Bit 15
Bit 14
Bit 13
Bit 12
Bit 11
Bit 10
Bit 9
Bit 8
Term A
Term11
Term X
Term 12
Alarm
Auto*
High Fire
Low Fire*
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
IS
Term W
Term 7
Term M
Term 6
Term 5
Internal
Safety
Delayed
Valve
Main
Valve
Blower
Pilot
Valve
Ignition
Note: A “1” in any bit position indicates the output or terminal is on or active.
*Note: bit 10 is Low Fire and bit 8 is Auto for YUV, YUVSC, YFR, YDC models
Note: For YP148/YP184 programmers, Term W is Ignition, Term 5 is Pilot, Term 6 is Main Valve 1 and Term 7 is Main Valve 2.
Table 23: YZ300
YZ300 LOWER (40901) – REFER TO BULLETIN YZEM-3001
Bit 7
Bit 0
Term 47
Term 46
Term 44*
Term 43
Term 3
Term 42
Term 41
Term 40
Low Oil Temp
High Oil
Temp
Low Water
High Water
Aux #3
Aux #2
Aux #1
Op Control
* Terminals 44 and 45 are internally connected
YZ300 MIDDLE (40902) – REFER TO BULLETIN YZEM-3001
Bit 7
Bit 0
Term 57
Term 56
Term 55
Term 54*
Term 52
Term 51
Term 49*
Term 48
Aux #4
High Temp
High Pres-
sure
Aux Gas
High Gas
Pressure
Low Gas
Pressure
Low Atomizing
Media
Low Oil
Pressure
* Terminals 49 and 50 are internally connected * Terminals 53 and 54 are internally connected
YZ300 UPPER (40903) – REFER TO BULLETIN YZEM-3001
Bit 7
Bit 0
Term P
Term 60
Term 59
Term 58
Unused
Unused
Unused
Unused
Air Flow
Aux #7
Aux #6
Aux #5
* Unused Bits 4-7 will always return 0
Figure 28. DEFAULT WIRING FOR YZ300 INTERLOCK ANNUNCIATOR
