Fisher FIELDVUE DVC6200f User Manual

Instruction Manual
D103412X012
Detailed Setup—Transducer Block
July 2013
111
Note
Because individual views are limited in size, View Lists 3 and 4 have multiple parts.
Table 4‐17. Transducer Block, View 3.1
Index Number Parameter
1 ST_REV
5.1 MODE_BLOCK.TARGET
5.2 MODE_BLOCK.ACTUAL
5.3 MODE_BLOCK.PERMITTED
5.4 MODE_BLOCK.NORMAL
6 BLOCK_ERR
10 TRANSDUCER_TYPE
11 XD_ERROR
13.1 FINAL_VALUE.STATUS
13.2 FINAL_VALUE.VALUE
17.1 FINAL_POSITION_VALUE.STATUS
17.2 FINAL_POSITION_VALUE.VALUE
32.1 SETPOINT_D.STATUS
32.2 SETPOINT_D.VALUE
35.1 SUPPLY_PRESSURE.STATUS
35.2 SUPPLY_PRESSURE.VALUE
36.1 PRESSURE_A.STATUS
36.2 PRESSURE_A.VALUE
37.1 PRESSURE_B.STATUS
37.2 PRESSURE_B.VALUE
38.1 PRESSURE_DIFF.STATUS
38.2 PRESSURE_DIFF.VALUE
48 TEMPERATURE
49 TRAVEL_TARGET
52 TRAVEL_DEVIATION
53 DRIVE_SIGNAL
54 DRIVE_CURRENT
55 MLFB
59 FAILED_ACTIVE
60 MAINT_ACTIVE
61 ADVISE_ACTIVE
71 RECOMMEND_ACTION
72 TRAVEL_ACCUM
73 CYCLE_COUNT
75.1 INST_ALERTS_ENABLE.ELECT_ENABLE
75.2 INST_ALERTS_ENABLE.SENSOR_ENABLE
75.3 INST_ALERTS_ENABLE.ENVIRO_ENABLE
75.4 INST_ALERTS_ENABLE.TRAVEL_ENABLE
75.5 INST_ALERTS_ENABLE.PROX_ENABLE
75.6 INST_ALERTS_ENABLE.TVL_HISTORY_ENABLE
75.7 INST_ALERTS_ENABLE.PERF_ENABLE
Table 4‐18. Transducer Block, View 3.2
Index Number Parameter
1 ST_REV
74.1 INST_ALERTS_ACTIVE.ELECT_ACTIVE
74.2 INST_ALERTS_ACTIVE.SENSOR_ACTIVE
74.3 INST_ALERTS_ACTIVE.ENVIRO_ACTIVE
74.4 INST_ALERTS_ACTIVE.TRAVEL_ACTIVE
74.5 INST_ALERTS_ACTIVE.PROX_ACTIVE
74.6 INST_ALERTS_ACTIVE.TVL_HISTORY_ACTIVE
74.7 INST_ALERTS_ACTIVE.PERF_ACTIVE
74.8 INST_ALERTS_ACTIVE.PD_EVENT_ACTIVE
74.9 INST_ALERTS_ACTIVE.PD_DETAIL1_ACTIVE
74.10 INST_ALERTS_ACTIVE.PD_DETAIL2_ACTIVE
74.11 INST_ALERTS_ACTIVE.PD_DETAIL3_ACTIVE
74.12 INST_ALERTS_ACTIVE.PD_DETAIL4_ACTIVE
74.13 INST_ALERTS_ACTIVE.PD_DETAIL5_ACTIVE
78 SELFTEST_STATUS
79 HEALTH_INDEX
86.1 DEVICE_RECORD.TEMP_MAX
86.2 DEVICE_RECORD.TEMP_MAX_TIME
86.3 DEVICE_RECORD.TEMP_MIN
86.4 DEVICE_RECORD.TEMP_MIN_TIME
86.5 DEVICE_RECORD.SUPP_PRESS_MAX
86.6 DEVICE_RECORD.SUPP_PRESS_MAX_TIME
86.7 DEVICE_RECORD.SUPP_PRESS_MIN
86.8 DEVICE_RECORD.SUPP_PRESS_MIN_TIME
Table 4‐19. Transducer Block, View 4.1
Index Number Parameter
1 ST_REV
3 STRATEGY
4 ALERT_KEY
10 TRANSDUCER_TYPE
22 ACT_MAN_ID
23 ACT_MODEL_NUM
24 ACT_SN
25 VALVE_MAN_ID
26 VALVE_MODEL_NUM
