Fisher FIELDVUE DVC6200f User Manual

Instruction Manual
D103412X012
Detailed Setup—Transducer Block
July 2013
112
Table 4‐20. Transducer Block, View 4.2
Index Number Parameter
1 ST_REV
27 VALVE_SN
28 VALVE_TYPE
29 XD_CAL_LOC
30 XD_CAL_DATE
31 XD_CAL_WHO
89 TEMPERATURE_UNITS
90 PRESSURE_UNITS
91 TVL_UNITS
92 LENGTH_UNITS
93 AREA_UNITS
94 SPRING_RATE_UNITS
Table 4‐21. Transducer Block, View 4.3
Index Number Parameter
1 ST_REV
39 PWA_SIMULATE
41.1 TVL_PRESS_CONTROL.TVL_PRESS_SELECT
41.2 TVL_PRESS_CONTROL.TVL_PRESS_STATE
42.1 BASIC_SETUP.ACTUATOR_STYLE
42.2 BASIC_SETUP.ZERO_PWR_COND
42.3 BASIC_SETUP.TRAVEL_SEN_MOTION
42.4 BASIC_SETUP.FEEDBACK_CONN
42.5 BASIC_SETUP.RELAY_TYPE
42.6 BASIC_SETUP.MAX_SUPP_PRESS
42.7 BASIC_SETUP.PRESS_RANGE_HI
42.8 BASIC_SETUP.PRESS_RANGE_LO
42.9 BASIC_SETUP.TVL_CAL_TRIGGER
42.10 BASIC_SETUP.TVL_TUNING_SET
42.11 BASIC_SETUP.PRESS_TUNING_SET
44.1 TRAVEL_TUNE.TVL_INTEG_ENABLE
44.2 TRAVEL_TUNE.TVL_INTEG_LIM_HI
44.3 TRAVEL_TUNE.TVL_INTEG_LIM_LO
44.4 TRAVEL_TUNE.TVL_INTEG_DEADZ
44.5 TRAVEL_TUNE.TVL_MLFB_GAIN
47.1 PRESS_TUNE.PRESS_CUTOFF_HI
47.2 PRESS_TUNE.PRESS_CUTOFF_LO
47.3 PRESS_TUNE.PRESS_PROP_GAIN
47.4 PRESS_TUNE.PRESS_INTEG_GAIN
47.5 PRESS_TUNE.PRESS_RATE_GAIN
47.6 PRESS_TUNE.PRESS_INTEG_DEADZ
47.7 PRESS_TUNE.PRESS_INTEG_HI_LIM
47.8 PRESS_TUNE.PRESS_INTEG_LO_LIM
47.9 PRESS_TUNE.PRESS_INTEG_IC_HI
47.10 PRESS_TUNE.PRESS_INTEG_IC_LO
47.11 PRESS_TUNE.PRESS_MLFB_GAIN
62 FAILED_ENABLE
63 MAINT_ENABLE
64 ADVISE_ENABLE
65 FAILED_MASK
66 MAINT_MASK
-continued-
Table 4‐21. Transducer Block, View 4.3 (continued)
Index Number Parameter
67 ADVISE_MASK
68 FAILED_PRI
69 MAINT_PRI
70 ADVISE_PRI
Table 4‐22. Transducer Block, View 4.4
Index Number Parameter
1 ST_REV
76.1 INST_ALERTS_CONFIG.SHUTDOWN_TRIGGER
76.2 INST_ALERTS_CONFIG.SHUTDOWN_RECOVERY
76.3 INST_ALERTS_CONFIG.OUTPUT_BLK_TIMEOUT
76.4 INST_ALERTS_CONFIG.DRIVE_CURRENT_ALRT_PT
76.5 INST_ALERTS_CONFIG.DRIVE_CURRENT_TIME
76.6 INST_ALERTS_CONFIG.TEMP_HI_ALRT_PT
76.7 INST_ALERTS_CONFIG.TEMP_LO_ALRT_PT
76.8 INST_ALERTS_CONFIG.SUP_PRES_HI_ALRT_PT
76.9 INST_ALERTS_CONFIG.SUP_PRES_LO_ALRT_PT
77.1 INST_ALERTS_CONFIG2.TVL_DEV_ALRT_PT
77.2 INST_ALERTS_CONFIG2.TVL_DEV_TIME
77.3 INST_ALERTS_CONFIG2.TVL_DEV_DB
77.4 INST_ALERTS_CONFIG2.TVL_ACCUM_ALRT_PT
77.5 INST_ALERTS_CONFIG2.TVL_ACCUM_DB
77.6 INST_ALERTS_CONFIG2.CYCLE_COUNT_ALRT_PT
77.7 INST_ALERTS_CONFIG2.CYCLE_COUNT_DB
77.8 INST_ALERTS_CONFIG2.TVL_OPEN_ALRT_PT
77.9 INST_ALERTS_CONFIG2.TVL_OPEN_DB
77.10 INST_ALERTS_CONFIG2.TVL_CLOSED_ALRT_PT
77.11 INST_ALERTS_CONFIG2.TVL_CLOSED_DB
77.12 INST_ALERTS_CONFIG2.TVL_LO_LO_ALRT_PT
77.13 INST_ALERTS_CONFIG2.TVL_LO_LO_DB
77.14 INST_ALERTS_CONFIG2.TVL_LO_ALRT_PT
77.15 INST_ALERTS_CONFIG2.TVL_LO_DB
77.16 INST_ALERTS_CONFIG2.TVL_HI_ALRT_PT
77.17 INST_ALERTS_CONFIG2.TVL_HI_DB
77.18 INST_ALERTS_CONFIG2.TVL_HI_HI_ALRT_PT
77.19 INST_ALERTS_CONFIG2.TVL_HI_HI_DB
82 UPGRADE_PROGRESS
87 PROTECTION
Table 4‐23. Transducer Block View, 4.5
Index Number Parameter
1 ST_REV
95.1 MAI_CHANNEL_1
95.2 MAI_CHANNEL_2
95.3 MAI_CHANNEL_3
95.4 MAI_CHANNEL_4
95.5 MAI_CHANNEL_5
95.6 MAI_CHANNEL_6
95.7 MAI_CHANNEL_7
95.8 MAI_CHANNEL_8
96 OUTBLOCK_SEL
97 PWA_SET_STATUS
