Fisher FIELDVUE DVC6200f User Manual

Instruction Manual
D103412X012
Detailed Setup—ISEL Function Block
July 2013
156
Table 4‐40. Input Selector Function Block Parameter Definitions (Continued)
Description
Initial
Value
Range
Block
Mode
RO / RW
Index
Number
Label
PARAMETER_NAME
Disable Analog Input 7
DISABLE_7
31 ALL
Value
BAD
NC
constant
Data Type: DS‐66
Enable/Disable for Input_7, If parameter is TRUE then
input is disabled. If parameter status is BAD it is not
evaluated.
Status
0=Use
1=Disable
0
Disable Analog Input 8
DISABLE_8
32 ALL
Value
BAD
NC
constant
Data Type: DS‐66
Enable/Disable for Input_8, If parameter is TRUE then
input is disabled. If parameter status is BAD it is not
evaluated.
Status
0=Use
1=Disable
0
Number used to average
AVG_USE
33 1 to 8 0
Data Type: Unsigned8
Number used to average the output. The number of
min and max dropped is the number of inputs minus
AVG_USE.
Alarm Summary
ALARM_SUM
34
Data Type: DS‐74
Current alert status, unacknowledged states,
unreported states, and disabled states of the alarms
associated with the function block.
CURRENT 34.1 RO NA
1: Hi Hi
2: Hi
3: Lo Lo
4: Lo
UNACKNOWLEDGED 34.2 RO NA
UNREPORTED 34.3 RO NA
DISABLED 34.4 RW ALL
Acknowledge Option
ACK_OPTION
35 ALL
1: Hi Hi
2: Hi
3: Lo Lo
4: Lo
0
Data Type: Bit String
Selection of whether alarms associated with the block
will be automatically acknowledged.
0=Disable
1=Enable
Alarm Hysteresis
ALARM_HYS
36 ALL 0 to 50% 0.50%
Data Type: Float
Hysteresis on alarms
High High Priority
HI_HI_PRI
37 ALL 0 TO 15 0
Data Type: Unsigned8
Priority of the alarm
High High Limit
HI_HI_LIM
38 ALL 0
Data Type: Float
Value of analog input which will generate an alarm
High Priority
HI_PRI
39 ALL 0 TO 15 0
Data Type: Unsigned8
Priority of the alarm
High Limit
HI_LIM
40 ALL 0
Data Type: Float
Value of analog input which will generate an alarm
Low Priority
LO_PRI
41 ALL 0 TO 15 0
Data Type: Unsigned8
Priority of the alarm
Low Limit
LO_LIM
42 ALL 0
Data Type: Float
Value of analog input which will generate an alarm
Low Low Priority
LO_LO_PRI
43 ALL 0 TO 15 0
Data Type: Unsigned8
Priority of the alarm
Low Low Limit
LO_LO_LIM
44 ALL 0
Data Type: Float
Value of analog input which will generate an alarm
High High Alarm
HI_HI_ALM
45
Data Type: DS‐71
The high high alarm data, which includes a value of the
alarm, a timestamp of occurrence, and the state of the
alarm.
UNACKNOWLEDGED 45.1 RW N/A
0=Undefined
1=Acknowledged
2=
Unacknowledged
0
ALARM_STATE 45.2 RO N/A
0=Undefined
1=Clear reported
2=Clear not reported
3=Active reported
4=Active not
reported
0
TIME_STAMP 45.3 RO N/A 0
SUBCODE 45.4 RO N/A 0
VALUE 45.5 RO N/A 0
-Continued-
