Fisher FIELDVUE DVC6200f User Manual

Instruction Manual
D103412X012
Detailed Setup—Resource Block
July 2013
61
View Lists
View lists allow the values of a set of parameters to be accessed at the same time. Views 1 and 2 contain operating
parameters and are defined by the Fieldbus Foundation. View 3 contains dynamic parameters and View 4 contains
static parameters with configuration and maintenance information. Views 3 and 4 are defined by the manufacturer.
Table 4‐4. Resource Block, View 1
Index Number Parameter
1 ST_REV
5.1 MODE_BLK.TARGET_MODE
5.2 MODE_BLK.ACTUAL_MODE
5.3 MODE_BLK.PERMITTED_MODE
5.4 MODE_BLK.NORMAL_MODE
6 BLOCK_ERR
7 RS_STATE
25 FREE_TIME
28 FAULT_STATE
37.1 ALARM_SUM.CURRENT
37.2 ALARM_SUM.UNACKNOWLEDGED
37.3 ALARM_SUM.UNREPORTED
37.4 ALARM_SUM.DISABLED
Table 4‐5. Resource Block, View 2
Index Number Parameter
1 ST_REV
14.1 GRANT_DENY.GRANT
14.2 GRANT_DENY.DENY
18 FEATURE_SEL
20 CYCLE_SEL
23 NV_CYCLE_T
24 FREE_SPACE
26 SHED_RCAS
27 SHED_ROUT
32 LIM_NOTIFY
33 CONFIRM_TIME
34 WRITE_LOCK
Table 4‐6. Resource Block, View 3
Index Number Parameter
1 ST_REV
5.1 MODE_BLK.TARGET_MODE
5.2 MODE_BLK.ACTUAL_MODE
5.3 MODE_BLK.PERMITTED_MODE
5.4 MODE_BLK.NORMAL_MODE
6 BLOCK_ERR
7 RS_STATE
25 FREE_TIME
28 FAULT_STATE
37.1 ALARM_SUM.CURRENT
37.2 ALARM_SUM.UNACKNOWLEDGED
37.3 ALARM_SUM.UNREPORTED
-continued-
Table 4‐6. Resource Block, View 3 (continued)
Index Number Parameter
37.4 ALARM_SUM.DISABLED
44 FB_OPTIONS
52 DETAILED_STATUS
53 TIME_SINCE_RESET
54 DEVICE_ID
Table 4‐7. Resource Block, View 4
Index
Number
Parameter
1 ST_REV
3 STRATEGY
4 ALERT_KEY
10 MANUFAC_ID
11 DEV_TYPE
12 DEV_REV
13 DD_REV
15 HARD_TYPES
17 FEATURES
19 CYCLE_TYPE
21 MIN_CYCLE_T
22 MEMORY_SIZE
31 MAX_NOTIFY
38 ACK_OPTION
39 WRITE_PRI
41 ITK_VER
42 DISTRIBUTOR
43 DEV_STRING
45 DIAG_OPTIONS
46 MISC_OPTIONS
47.1 FIRMWARE_REVISION.FIRMWARE_REV_MAJOR
47.2 FIRMWARE_REVISION.FIRMWARE_REV_MINOR
47.3 FIRMWARE_REVISION.FIRMWARE_REV_BUILD
47.4 FIRMWARE_REVISION.IO_FIRMWARE_REV
47.5 FIRMWARE_REVISION.DIAG_CAL_REV
47.6 FIRMWARE_REVISION.FIRMWARE_REV_ALL
48 HARDWARE_REV
49 ELECTRONICS_SN
50 FACTORY_SN
51 FIELD_SN
55.1 STBY_FIRMWARE_REV.STBY_FIRMWARE_REV_MAJOR
55.2 STBY_FIRMWARE_REV.STBY_FIRMWARE_REV_MINOR
55.3 STBY_FIRMWARE_REV.STBY_FIRMWARE_REV_BUILD
55.4 STBY_FIRMWARE_REV.STBY_IO_FIRMWARE_REV
55.5 STBY_FIRMWARE_REV.STBY_DIAG_CAL_REV
55.6 STBY_FIRMWARE_REV.STBY_FIRMWARE_REV_ALL
