Fisher FIELDVUE DVC6200f User Manual

Instruction Manual
D103412X012
Detailed Setup—Transducer Block
July 2013
91
Table 4‐14. Transducer Block Parameter Definitions (Continued)
Description
Protect
Category
Initial ValueRangeMode
RO /
RW
Index
Number
Label
PARAMETER_NAME
PRESSURE_DIFF
38
Data Type: DS‐65
STATUS indicates the validity of
VALUE. VALUE is the difference
between PRESSURE_A and
PRESSURE_B, controls AI channel 8.
Pressure Differential Status
STATUS
38.1 RO N/A N/A
Pressure Differential
VALUE
38.2 RO N/A N/A
PWA Simulate
PWA_SIMULATE
39
RO or
RW*
ALL
1=Simulate Off
2=Simulate Enabled
1=Simulate Off ALL
Data Type: Enum (Uint8)
When this is set to 2 all the alert
ACTIVE parameters can be written,
except for INST_ALERTS_ACTIVE.
SHUTDOWN_ALERT_ACTIVE. This
allows alerts to be simulated for
testing with hosts. NOTE: only
ACTIVE parameters are affected by
this. * PWA Simulate is RW only if a
jumper is installed across the Aux
Terminal. If no jumpered is installed
across the Aux Terminal, PWA
Simulate is RO.
Grant Deny
GRANT_DENY
40
GRANT 40.1 RW ALL
0: Program
1: Tune
2: Alarm
3: Local
all bits cleared NONE
Data Type: DS‐50
Options for controlling access of
host computer and local control
panels to operating, tuning, and
alarm parameters of the block. Has
no effect on the DVC6200f.
GRANT: 0=N/A, 1= granted
DENY: 0=N/A, 1= denied
DENY 40.2 RW ALL all bits cleared NONE
Travel Pressure Control
TVL_PRESS_CONTROL
41
Travel/Pressure Select
TVL_PRESS_SELECT
41.1 RW ALL
1=Travel
2=Pressure
3=TVL/PRESS Auto Recv
4=TVL/PRESS Man Recv
1=Travel SETUP
Data Type: Enum (Uint8)
Selects whether travel sensor or port
A pressure is used for feedback.
Travel/Pressure State
TVL_PRESS_STATE
41.2 RO N/A
1=Travel
2=Pressure
N/A
Data Type: Enum (Uint8)
Indicates which sensor is used for
feedback
-Continued-
