Fisher FIELDVUE DVC6200f User Manual

Instruction Manual
D103412X012
Detailed Setup—Transducer Block
July 2013
92
Table 4‐14. Transducer Block Parameter Definitions (Continued)
Description
Protect
Category
Initial ValueRangeMode
RO /
RW
Index
Number
Label
PARAMETER_NAME
Basic Setup
BASIC_SETUP
42
Actuator Style
ACTUATOR_STYLE
42.1 RW
MAN
OOS
1=Spring & Diaphragm
2=Piston‐Dbl w/o Spring
3=Piston‐Dbl w/Spring
4=Piston Sgl w/Spring
1=Spring &
Diaphragm
SETUP Data Type: Enum (Uint8)
Zero Power Condition
ZERO_PWR_COND
42.2 RW
MAN
OOS
1=Valve Closed
2=Valve Open
1=Valve Closed SETUP
Data Type: (Uint8)
Enum Identifies whether the valve is
open or closed when instrument
power is lost.
Travel Sensor Motion
TRAVEL_SEN_MOTION
42.3 RW
MAN
OOS
1=Counter Clockwise
2=Clockwise
1=Counter
Clockwise
SETUP Data Type: Enum (Uint8)
Feedback Connection
FEEDBACK_CONN
42.4 RW
MAN
OOS
100: Default Array
64: SStem #19 Array
65: SStem #25 Array
66: SStem #38 Array
67: SStem #50 Array
70: SStem #100 Array
74: SStem #200 Array
85: SStem #1 Roller
Array
90: RShaft End Array
95: RShaft #1 Window
Array
97: RShaft #2 Window
Array
SETUP Data Type: Enum (Uint8)
Relay Type
RELAY_TYPE
42.5 RW
MAN
OOS
1=Relay A or C‐‐Double or
Single Direct
2=Relay B‐‐Single Reverse
5=Relay C‐Special App.
‐‐Single Direct
6=Relay B‐Special App.
‐‐Single Reverse
9=Lo‐Bleed Relay A or
C‐‐Double or Single
Direct
10=Lo‐Bleed Relay B‐‐
Single Reverse
13=Lo‐Bleed Relay
C‐Special App.‐‐Single
Direct
10=Lo‐Bleed Relay
B‐Special App.‐-Single
Reverse
=Relay A or
C‐‐Double or
Single Direct
SETUP Data Type: Enum (Uint8)
Maximum Supply Pressure
MAX_SUPP_PRESS
42.6 RW
MAN
OOS
> 0, < = 150 35 psig SETUP Data Type: Float
Pressure Range Hi
PRESS_RANGE_HI
42.7 RW
MAN
OOS
> 0, < = 150 15.0 psig SETUP
Data Type: Float
Defines pressure corresponding to
max pressure in pressure control
mode.
Pressure Range Lo
PRESS_RANGE_LO
42.8 RW
MAN
OOS
> = 0, < = 150 3.0 psig SETUP
Data Type: Float
Defines pressure corresponding to
minimum pressure in pressure
control mode.
Travel Calibration Trigger
TVL_CAL_TRIGGER
42.9 RW
MAN
OOS
1 = Aux Term ignored 1 SETUP Not available in the DVC6200f
Travel Tuning Set
TVL_TUNING_SET
42.10 RW
MAN
OOS
1=B, 2= C, ...12=M
23=X
2=C SETUP
Data Type: Enum (Uint8)
Letter (B through M or X)
Pressure Tuning Set
PRESS_TUNING_SET
42.11 RW
MAN
OOS
1=B, 2=C, ...12= M
23=X
2=C SETUP
Data Type: Enum (Uint8)
Letter (B through M or X)
-Continued-
