Fisher FIELDVUE DVC6200f User Manual

Instruction Manual
D103412X012
Detailed Setup—Transducer Block
July 2013
93
Table 4‐14. Transducer Block Parameter Definitions (Continued)
Description
Protect
Category
Initial ValueRangeMode
RO /
RW
Index
Number
Label
PARAMETER_NAME
TRAVEL_CAL
43
Travel Count
TVL_COUNT
43.1 RO N/A
Data Type: Uint16
Raw feedback from Travel Sensor
Travel Hi Calibration
TVL_HI_CAL
43.2 RW
MAN
OOS
<TVL_FAC_HI
>TVL_LO_CAL
CAL
Data Type: Uint16
Maximum drive calibration point
Travel Lo Calibration
TVL_LO_CAL
43.3 RW
MAN
OOS
>TVL_FAC_LO
<TVL_HI_CAL
CAL
Data Type: Uint16
Minimum drive calibration point
Travel Crossover
TVL_CROSSOVER
43.4 RW
MAN
OOS
>0% < = 100% 50% CAL
Data Type: Float
Not used for the DVC6200f
Travel Fac Hi
TVL_FAC_HI
43.5 RO N/A Set by Factory N/A
Data Type: Uint16
Maximum value of travel sensor
counts. Set at factory.
Travel Fac Lo
TVL_FAC_LO
43.6 RO N/A Set by Factory N/A
Data Type: Uint16
Minimum value of travel sensor
counts. Set at factory.
Travel IP Bias
TVL_IP_BIAS
43.7 RW
MAN
OOS
0% - 100% 70% CAL Data Type: Float
Travel MLFB Bias
TVL_MLFB_BIAS
43.8 RW
MAN
OOS
0 - 100% 50% CAL Data Type: Float
Last Calibration Type
TVL_CAL_TYPE
43.9 RW
MAN
OOS
0: Not Calibrated
1: Single Point Calibration
2: Auto Calibration
3: Manual Calibration
2: Auto Calibration CAL Data Type: Enum (Uint8)
TRAVEL_TUNE
44
Travel Integral Enable
TVL_INTEG_ENABLE
44.1 RW
MAN
OOS
1=Off
2=On
2=On SETUP Data Type: Enum (Uint8)
Travel Integral Limit Hi
TVL_INTEG_LIM_HI
44.2 RW
MAN
OOS
0% - 100% 30% SETUP Data Type: Float
Travel Integral Limit Lo
TVL_INTEG_LIM_LO
44.3 RW
MAN
OOS
-100% - 0% -30% SETUP Data Type: Float
Travel Integral Dead Zone
TVL_INTEG_DEADZ
44.4 RW
MAN
OOS
0% - 2% 0.25% SETUP Data Type: Float
Travel MLFB Gain
TVL_MLFB_GAIN
44.5 RW
MAN
OOS
> = 0 35 SETUP Data Type: Float
-Continued-
