Fisher FIELDVUE DVC6200f User Manual

Instruction Manual
D103412X012
Detailed Setup—Transducer Block
July 2013
94
Table 4‐14. Transducer Block Parameter Definitions (Continued)
Description
Protect
Category
Initial ValueRangeMode
RO /
RW
Index
Number
Label
PARAMETER_NAME
TRAVEL_CAL_RUN
45
Travel Calibration Command
TVL_CAL_CMD
45.1 RW MAN
1: Operating
2: Autocalibrate
3: Not Used by DVC6200f
4: Mark Full Open
5: Mark Full Closed
6: Manual Calibrate Final
7: Abort
8: Clear Cal Status
9: Manual Calibrate Init
10: Manual Calibrate
Restore
11: Reset Travel Sensor
Error
12: Reserved
13: Execute Performance
Tuner
14: Execute Performance
Tuner (Graphite Packing)
16: Execute Performance
Tuner (Booster)
17: Execute Performance
Tuner (Graphite Packing
and Booster)
19: Autocalibration, Set
Filter
20: Autocalibrate
Extended, Set Filter
1=Operating CAL
Data Type: Enum (Uint8)
Resets to 1 after a write
Travel Calibration Prog
TVL_CAL_PROG
45.2 RO N/A 0% N/A Data Type: Uint8
Travel Calibration Status
TVL_CAL_STATUS
45.3 RO N/A
0: auto cal complete
1: calibration complete
2: auto cal in progress
3: manual cal in progress
3: Not Used by DVC6200f
5: upper position marked
6: lower position marked
7: calibration error
8: Performance Tuner
active
9: Performance Tuner
Success
10: Performance Tuner
Error (No movement)
11: Performance Tuner
Error (Accessories
unstable)
12: Performance Tuner
Error (Other)
no bits set N/A
Data Type: Bit String (2 bytes)
All bits set to 0 when mode changes
from OOS. 0 = FALSE,
1 = TRUE
Reserved

TVL_CAL_RESERVED
45.4 Reserved
-Continued-
