Lit. No. 43894, Rev. 02 38 November 1, 2016
OPERATING YOUR SNOWPLOW
Automatic Shutdown
The control will automatically turn OFF after being
idle for 20 minutes. To reactivate the control after
a shutdown, press the ON/OFF button.
Smooth Stop/Soft Stop
The control automatically allows the blade to coast
to a stop when the button is released. This results
in smoother operation, reduces the shock to the
hydraulic system, and increases hose and valve
life. See "FLEET FLEX Electrical System" in this
section for more information.
Control Functions
Raise, Lower, Float, Angle
The four diamond‑shaped buttons in the center of
the control face, when pressed, will result in the
blade movements described in the table.
Function Description of Operation
RAISE
Press this button to raise the blade and
cancel FLOAT mode. Function times out
after 3.0 (straight blades), 4.0 (XtremeV™,
XV2™) or 3.5 (XLS™) seconds.
LOWER
Press this button to lower the blade.
Release the button to stop the blade at
desired height.
FLOAT
†
Press the LOWER button and hold
3/4 second to activate this mode. The
FLOAT light in the upper right corner
of the control face will illuminate. The
blade will lower to the ground surface
and follow the contour of the surface as
it dips or raises. Function does not time
out; however, control will shut down after
20 minutes of nonuse.
Press the RAISE button momentarily to
cancel FLOAT. Angling left or right will not
interrupt (pause) the FLOAT function.
†
FLOAT mode activates immediately when one‑touch FLOAT
feature is enabled. See "One‑Touch FLOAT" in this section
for more information.
