Lit. No. 43894, Rev. 02 40 November 1, 2016
OPERATING YOUR SNOWPLOW
Wing Positions
XtremeV™, XV2™, and XLS™ Blades
The two round buttons located to the left and
right of the LOWER button move either wing
independently of the other as described in the
following table.
SECURITY GUARD™ System (1, 2, 3, 4)
The four round buttons located to the left and
right of the LOWER and RAISE buttons will
also operate the SECURITY GUARD system (if
equipped). See "SECURITY GUARD System" in
this section for more information.
Function Description of Operation
L WING
Press this button on the left side of the
control to move the left wing. The rst
time the button is pressed after the
control is turned ON or another function
is used, the wing will extend. Repeated
use of the same button, without using
another function, results in movement in
the opposite direction from the previous
movement. Function times out after
3.0 (XtremeV, XV2), 3.75 (XLS – OUT) or
3.25 (XLS – IN) seconds.
R WING
Press this button on the right side of
the control to move the right wing. The
rst time the button is pressed after the
control is turned ON or another function
is used, the wing will extend. Repeated
use of the same button, without using
another function, results in movement in
the opposite direction from the previous
movement. Function times out after
3.0 (XtremeV, XV2), 3.75 (XLS – OUT) or
3.25 (XLS – IN) seconds.
LOWER
RL
