Lit. No. 43894, Rev. 02 45 November 1, 2016
OPERATING YOUR SNOWPLOW
Wing Positions
XtremeV™, XV2™, and XLS™ Blades
Moving the control lever from the center position
toward the words WING IN/OUT, on either side of
the face of the control body will cause either wing
to move independently of the other as described in
the following table.
NOTE: If a control function times out before
desired blade movement is complete, release
the lever to the center position, then move it
back into the desired function.
SECURITY GUARD™ System (1, 2, 3, 4)
Moving the control lever from the center
position toward any of the four digits on the
face of the control body will also operate the
SECURITY GUARD system (if equipped). See
"SECURITY GUARD System" in this section for
more information.
Function Description of Operation
L WING
IN/OUT
Move the control lever toward the left side
of LOWER on the control face to move
the left wing. The rst time the lever is
moved into the slot after the control is
turned ON or another function is used,
the wing will extend. Repeated use of
the lever in the same slot, without using
another function, results in movement in
the opposite direction from the previous
movement. Function times out after
3.0 (XtremeV, XV2), 3.75 (XLS – OUT) or
3.25 (XLS – IN) seconds.
R WING
IN/OUT
Move the control lever toward the right
side of LOWER on the control face to
move the right wing. The rst time the
lever is moved into the slot after the
control is turned ON or another function is
used, the wing will extend. Repeated use
of the lever in the same slot, without using
another function, results in movement in
the opposite direction from the previous
movement. Function times out after
3.0 (XtremeV, XV2), 3.75 (XLS – OUT) or
3.25 (XLS – IN) seconds.
