(lowered)
Attachment
Arm
Connecting
Pin
Jack
(raised)
Jack Lock
Pin Release
Handle (raised)
DETACHING SNOWPLOW FROM VEHICLE & STORAGE
Detach HT Series™ Blade
NOTE: Place electrical plugs in storage
position. The driver-side and center plug
on 3-plug electrical systems are joined for
storage. The passenger-side and 2-plug
systems are equipped with plug covers.
