Lit. No. 43894, Rev. 02 95 November 1, 2016
To DS
Angle Ram
To PS
Angle Ram
To Lift
Ram Base
To Lift
Ram Rod
Hose Routing – HT Series™ Straight Blades
MAINTENANCE
Hose Routing – XtremeV™ and XV2™ Blades
From Passenger
Side Rod (Front)
Fr
om Driver Side
Base (Rear)
From Passenger
Side Base (Rear)
From Lift Ram
From Driver Side
Rod (Front)
