Flexim FLUXUS F501 User Manual

9 Measurement
9.2 Measurement settings FLUXUS F501
2020-06-30, UMFLUXUS_F501V1-3EN
76
Terminal assignment
The terminals for the connection of the output are displayed.
• Press ENTER.
It will be displayed whether the current output is active or passive (here: active).
Tab. 9.3: Examples for the error output (output range: 4...20 mA)
list item output signal
Minimum (4.0 mA)
Hold last value
Maximum (20.0 mA)
Other value...
error value = 3.5 mA
Special Funct.\SYSTEM settings\Proc. outputs\...\active loop I1
I [mA]
20
4
t
d
t
0
t
1
t
I [mA]
20
4
t
0
t
1
t
I [mA]
20
4
t
d
t
0
t
1
t
I [mA]
20
4
t
d
t
0
t
1
t
