9 Measurement
FLUXUS F501 9.2 Measurement settings
77
UMFLUXUS_F501V1-3EN, 2020-06-30
Output function test
The function of the output can now be tested.
• Connect an external measuring instrument to the terminals of the output.
• Enter a test value. It has to be within the output range.
• Press ENTER.
If the external measuring instrument displays the entered value, the output functions correctly.
• Select yes to repeat the test, no to return to the menu item SYSTEM settings.
• Press ENTER.
9.2.4 Activation of an analog output
The measuring range of the source item has to be entered.
• Press ENTER until Current Loop is displayed. Select yes to activate the output.
• Press ENTER.
Measuring range
After an analog output has been activated in the program branch Output Options, the measuring range of the source
item has to be entered.
• Select sign if the sign of the measured values is to be considered for the output.
• Select absolut if the sign of the measured values is not to be considered for the output.
• Press ENTER.
• Enter the lowest expected measured value. The unit of measurement of the source item will be displayed.
Zero-Scale Val. is the value assigned to the value Output MIN of the output range.
• Press ENTER.
Special Funct.\SYSTEM settings\Proc. outputs\...\Output Test I1
Special Funct.\SYSTEM settings\Proc. outputs\...\I1= 10 mA\Again?
Output Options
ENTER until
Current Loop
Meas.Values
Zero-Scale Val.
Full-Scale Val.
Test output
Error-val. delay
see annex A, p. 134
Notice!
An output can only be activated in the program branch
Output Options if it has previously been installed.
Output Options\...\Current Loop
Output Options\...\Meas.Values
Output Options\...\Zero-Scale Val.
