9 Measurement
9.4 Display of measured values FLUXUS G809
2020-06-25, UMFLUXUS_G809V2-2EN
106
HumanMux mode
The measured values of one channel are displayed in the HumanMux mode. The measurement on the other channels is
continued, but not displayed.
Select the command →Mux:Nextchan. to display the next activated channel. The measured values of the selected
channel will be displayed as configured in the program branch Output Options, see section 9.2.1.
9.4.3 Adjustment of the display
During the measurement, the display can be adapted in order to display 2 measured values at the same time (one in each
line of the display). This does not affect totalizing, storing of measured values, transmission of measured values, etc.
The following information can be displayed in the upper line:
The measured values of the physical quantity selected in the program branch Output Options can be displayed in the
lower line:
Press key during the measurement to change the display in the upper line, press key to change the display in the
lower line.
The character * indicates that the displayed value (here: flow velocity) is not the selected physical quantity.
Status line
Important information of the running measurement is summarized in the status line. Quality and precision of the running
measurement can be evaluated accordingly.
Press key during the measurement to scroll through the upper line to the status line.
display explanation
Mass Flow designation of the physical quantity
A: +8.879 m³ values of the totalizers, if activated
full date and time at which the data logger will be full, if activated
Mode measuring mode
L transducer distance
Transd. transducer temperature
Rx alarm state indication if activated and if alarm outputs are activated
display explanation
12.3 m/s flow velocity
1423 m/s sound speed
124 kg/h mass flow rate
15 m3/h standard volumetric flow rate or operating volumetric flow rate
Fig. 9.3: Display of the status line
A:Flow Velocity
* 2.47 m/s
A: S3 Q9 c RT F↓
