Configuration of the outputs
(see chapter 9)
Main menu Main menu
Special Funct. Output Options
for Channel x
SYSTEM settings
ENTER until
Proc. outputs
Current Loop
Install Output
→ Current
→ Frequency
→ Binary
yes no
Zero-Scale Val.
Enable Full-Scale Val.
Test output
yes no
Source chan.
→ all channels
Source item
Output range
Error-value
active loop
Output Test
1 2
