FlexRadio Systems Tuner Genius XL User Manual


Page27of 72
Copyright 2021 FlexRadio. All Rights Reserved. 7 June 2021(FW:0.9.12, Utility: 0.9.12)
 Connectthetuner'sPTTOutput(portAorB)totheexciterinplaceofthekeyingdevice.
Whenthetuneriskeyed,theTunerGeniusXL willmanagetheoutputkeyingsignaldelayandassertPTTatthe
transceiverwhenthetunerisreadytoacceptRF.

Example:FootswitchPTTwiringforatransceiverconnectedtoPortAthatdoesnothaveaTXDelayadjustment.
6.3.1.4 Band Data and Frequency Measurement based restrictions
Inthefollowingsectionswedescribemethodsforsupplyingthetunerwithbanddatainformationfrom
exciters.WhenthedataarrivesatthetuneroveraCATconnection,thefrequencyisprovidedtothetune rand
thetunerrecordsthetuningsolution associatedwiththefrequency.Upto20solutions,keyed
byfrequency
canbestoredforeachban d.
WhentheexciterdoesnotprovidedataviaaCATconnectionbutdoesprovidebandinformationviaaBCDor
Pin2Bandconnection,thetunerfindsatuningsolutionontheexciter'sfrequencythenstoresthatsolutionfor
theentireband.Onlyone
solutionisstoredperband.Significantchangesinfrequencywithinabandmay
requirere‐tuning.ThisalsoappliestoFrequencyMeasurementconfigurations.Ifthetunerhasnobanddata
input,butsensestheRFfrequency,itwillstoreonesolutionperband.
