FlexRadio Systems Tuner Genius XL User Manual


Page39of72
Copyright 2021 FlexRadio. All Rights Reserved. 7 June 2021(FW:0.9.12, Utility: 0.9.12)
6.3.3 Interfacing with the Power Genius XL (PGXL)
TheTunerGeniusisdesignedforinterfacingwiththePGXLandisstraightforward.PleasereferenceFigure2‐
 ConnectacoaxjumperbetweenthePortAoutputofthePGXLandthePortAinputofthetuner.
 ConnectacoaxjumperbetweenthePortBoutputofthePGXL
andthePortBinputofthetuner.
 EnsurethePGXLisconnectedtothesameLANasthetuner.
 EnsurethePGXLisappropriatelyconfigured(seethePowerGeniusXLUserGuide)andpairedwiththe
correctFlex6000transceiver.
That'sit!
6.3.4 Interfacing with Other Amplifiers
YoucanconnectmostHF+6mamplifierstoaTunerGeniusXL.However,forSO2Rswitchingmodels,each
amplifiermustbeexclusivelyconnectedtooneofthetunerTXports(AorB).Thougheachporthasmultiple
interfacestoreceivebanddataandPTTthetuner,theSO2Rversionwillwork
withtwoamplifiers,andthe1x3
versiondoesnotsupportinputsfrommorethanoneamplifier.
ThetunerrequiresbothbanddataandaPTTlinewhenusingamplifiers.
6.3.4.1 PTT
PTTiseasytoprovide,generallyrequiringasingletwo‐conductorcable.However,almostallamplifiersrequire
excitersthatdrivethemtodelayemittingRFuntiltheamplifierisreadytoamplifyit.TheTunergeniusalso
requiresashortdelayof<20msincaseswherethefrequencyusedalready
hasasolutionstoredinmemory.
Therefore,pleasetaketheTXandPTTdelayrequirementsoftheentireTXchainintoaccount.
6.3.4.2 Band and Frequency Data
Unlessyouareusingfrequencydetection,itisusuallytheresponsibilityoftheexcitertooriginatebandor
frequencydat atothecomponentsintheTXchainthatrequirethem.Therestrictiondescribedinsection
6.3.1.4,BandDataandFrequencyMeasurementbasedrestrictions,mayapply.
Ifanappropriatefrequencymemory
isnotstored,theSWRpresentedtotheamplifiermaybehigherthancan
safelybeused.Therefore,pleasetakeextracaretomakesureagoodtuningsolutionisactivebefore
transmitting,especiallywhenyouareQRO.
6.3.4.3 Ameritron
TBD
6.3.4.4 SPE
TBD
