7 Operating the Tuner Genius XL

7.1 Changing Modes

TheTunerGeniusXL providesthreeoperationalmodes:Standby,OperateandBypass.InStandbyandBypass

modes,thetunerdoesnotmodifyincomingoroutgoingsignals.InOperatemodetuningsolutionsareapplied

totheincomingandoutgoingsignals.

7.1.1 Bypass and Operate Modes

Therearetwowa ysthetunercanbetoggledbetweenBypassandOperat emodes.

1. BypressingtheBYPASS/OPERATEbuttononthefrontpanelofthetuner.

2. Bychangingthemodeusingsoftwaresuchastheutilityprogram.



Frontpanel"Hard"button



TunerGeniusXLWindowsUtilityButton

–Whenproperlyconfigured,aconvenientmethodforswitchingbetweenStandby,Operate,andBypass

modesusesoftwareconnectedtotheTunerGe niusXLovertheLAN.

ThefrontpanelBYP ASS/OPERA TEbuttonandtheutility'sBYPbuttontoggletheoperationalstatebetween

BypassandOperatemode.TheBYP ASSLEDonthe

TunerfrontpanelisonwhilethetunerisinBypassmode.

7.1.2 Standby Mode

InStandbymode,thetunerdisconnectsfromallantennas.Asaresult,tuningsolutionsthatmaybeapplied

whilereceivingarenotapplied.StandbycanbeenteredbypressingandholdingtheBYPASS/OPERA TEbutton

orusingtheSTBYbuttonintheutilityprogram.



FlexRadio Systems Tuner Genius XL User Manual
