Copyright 2021 FlexRadio. All Rights Reserved. 7 June 2021(FW:0.9.12, Utility: 0.9.12)
12 Specifications
Tuning: Fullyautomaticandmanualtuning
FrequencyRange: 1.8to30MHzcontinuouspluscoverageof6meters
RadioInterface: LAN,CATRS232,CIV,BCD,PintoBand(PTB),frequencysense.
AlarmsandWarnings: Lowdrive,FreqOutofRange,WrongBand,Highpower,>10:1
SWR
MatchingRange: Upto10:1SWR.
TuningTime: Tuningsolutions(2to12seconds)
Storedmemoryswitching: <20ms.
TuningPowerRequirement: 10W‐200W
RFPower 2000Wmaximum
ExciterInputs 2SO239
AntennaOutputs 2SO239
Antenna
Impedance 50ohmsunbalanced
CoolingThermostaticallyControlledFans
MechanicalSpecifications
Dimensions 11.8”Wx13.8”Dx5.9”H(30cmWx35cmDx15cmH)
Weight15.4pounds,7kg
OperatingTemperature 4°F(20°C)to+122°F(+50°C)
ElectricalSpecifications
SupplyVoltageandCurrent
12‐16VDC@2A
13 FCC Statement
Thisdevicecomplieswithpart15oftheFCCRules.Operationissubjecttothefollowingtwoconditions:
Thisdevicemaynotcauseharmfulinterference,and
thisdevicemustacceptanyinterfe rencereceived,includinginterferencethatmaycauseundesired
operation
FCCID:
2AK7NSKYTunerGeniusXL001

