5.2 Back Panel

Twobackpaneloptionsareavailable.

5.2.1 1x3 Antenna Switching Option

The1x3back‐paneloptionprovidesoneinputandthreeswitchableantennaoutputconnections.Thetunerwill

tunethesignalontheinput(TX)tothecurrentlyselectedoutput(ANT1,2,and3).OnlytheportAconnections

areactive,andthetunercanbecontrolledonlybyasingle

radio.



Figure 5-3 1x3 Antenna Switching Option
