FlexRadio Systems Tuner Genius XL User Manual


Page28of 72
Copyright 2021 FlexRadio. All Rights Reserved. 7 June 2021(FW:0.9.12, Utility: 0.9.12)
6.3.2 Interfacing with Other Exciters
YoucanconnectmorethanoneradiotypetoaTunerGeniusXL,providedeachradioisexclusivelyconnectedto
oneofthetunerports(AorB).Thougheachporthasmultipleinterfacestoreceiveband dataandkeythe
tuner,itdoesnotsupportmultipleradiosonasingle
tunerport.
6.3.2.1 Elecraft
ThetunerrequiresbothbanddataandaPTTlinefromElecraftradios.Banddataisavailableusingacustom
wiredBCDbanddecodercable.
PTT
Connectanappropriatecable(RCAmaleterminatedonbothends)betweentheradio'sKeyoutputandthePTT
InputcorrespondingtothetunerPortused
(AorB).
BandData(BCD)
Seethepinoutdiagrambelowforthecableconfiguration.Theconnectionisthesameforall Elecraftradio
models.


