FlexRadio Systems Tuner Genius XL User Manual


Page15of72
Copyright 2021 FlexRadio. All Rights Reserved. 7 June 2021(FW:0.9.12, Utility: 0.9.12)
6 Tuner Genius XL Setup, Configuration, and Testing
6.1 Unpacking and Setup
ThefollowingaccessoriesandmaterialsareincludedwithyourTunerGeniusXLtuner.Carefullyremovethe
tunerfromitsshippingcontainer,unpack,and identifytheitemslistedbelow:
 One(1)TunerGenius
 One(1)2m(6ft)DCpowercordwithconnectorandpigtails
 One(1)2m(6
ft)Ethernetcable
 One(1)TunerGeniusXLQuickStartGuide
Inadditiontotheabove,thefollowingarerequiredforthei nitialsetupofthetuner:
 HFor6‐mete rtransceiverandantennasystem
 Suitablecoaxjumpercablesforinterconnectionofthetransceiverandtuner

Windows™PCwithanethernetconnection,connectedtoalocalareanetwork(LAN).
PlaceyourTunerGeniusXLonaflat,stablesurface.Ensurethetunerhasatleast30cm(12inches)ofopen
spaceinfrontandbacktoensureadequatecooling.Then,followthesestepsandrefertothe
following
diagramstoconnectyourTunerGeniusXL.Forconnectionstonon‐FlexRadioproducts,pleaseseesection6.3,
AdvancedConfiguration.
6.1.1 1x3 Switch Model
 ConnectthetransceiverantennaoutputtothePortATXsocketonthetunerwithasuitable50‐ohm
coaxjumpercable.
 ConnectanantennatotheANT1antennasocket.
6.1.2 SO2R Switch Model
 ConnectthetransceiverantennaoutputtothePortATXsocketonthetunerwithasuitable50‐ohm
coaxjumpercable.
 ConnectanantennatothePORTAANTENNAsocket.
6.1.3 All Models
 ConnectthesuppliedEthernetcablefromtheRJ45socketonthetuner'sbackpaneltoanappropriate
switch
1
portonyourLAN.
2

 ApplytheDCpowercordtotheDCpowerinputonthetuner'sbackpanel.Connecttheotherendof
thepowercordtoasuitable12VDCto15VDCpowersource.Becarefultoobservecorrectpolarity. 
 Turnthetuneronusingthepowerswitchonthe
backpanel.

1
Mosthomerouterscontainintegralswitches.Whiletheuseofaseparateswitchforyourhamequipmentisstrongly
encouraged,itisnotarequirement.ALAN,however,isarequirementforconfiguringaTGXL.
2
AWindows™PCmustbepresentintheLANtocompletetheconfigur ationofthetuner.
